Please note: While we strive for accuracy in our descriptions and images, the actual color and appearance of the items may vary slightly from the photographs due to lighting conditions or varying computer monitor settings.

SKU: KSP40357
(0)

Kyocera SGS 40357 10mm 2 Flute Uncoated Carbide Square End Mill

Only 1 left
$175.33

Professional quality Kyocera SGS 40357 Series 03S general application end mill manufactured from solid carbide for reliable and precise milling performance. This 10mm diameter square end mill features two flutes, a regular length design, 30 degree right-hand spiral geometry and a bright uncoated finish for versatile machining across a wide range of workpiece materials.

The centre-cutting geometry allows for efficient plunging, slotting, profiling and general milling operations. Its 2-flute design provides effective chip evacuation, while the positive rake and right-hand cutting direction deliver smooth and stable cutting performance. This end mill is suitable for machining steel, stainless steel, cast iron, non-ferrous materials and high temperature alloys, with secondary application in hardened materials.

Product Specifications

  • Brand: Kyocera SGS
  • Part Number: 40357
  • Series: 03S
  • Application: General Application End Mill
  • End Mill Type: Square End
  • Cutting Diameter: 10mm (0.3937 inch)
  • Number of Flutes: 2
  • Length of Cut: 22mm (0.8661 inch)
  • Shank Diameter: 10mm (0.3937 inch)
  • Overall Length: 75mm (2.9528 inch)
  • Shank Length: 52.93mm (2.0840 inch)
  • Material: Solid Carbide
  • Coating: Bright/Uncoated
  • Shank Type: Straight
  • Flute Type: Spiral
  • Helix Angle: 30° Right Spiral
  • Cut Direction: Right Hand Cut Direction (RHC)
  • Rake Angle: Positive
  • Center Cutting: Yes
  • Variable Helix: No
  • Chip Breaker: No
  • Coolant Option: External Coolant
  • Tool Length: Regular
  • Weldon Flat: No
  • Cutting Diameter Tolerance: +0.000/-0.050mm
  • Shank Diameter Tolerance: h6
  • Primary Workpiece Materials: Steel, Stainless Steel, Cast Iron, Non-Ferrous Materials, High Temperature Alloys
  • Secondary Workpiece Material: Hardened Materials

The Kyocera SGS 40357 is an excellent choice for CNC milling applications requiring a durable 10mm 2-flute solid carbide square end mill with centre-cutting capability, 30° right-hand spiral geometry and bright uncoated finish for versatile precision machining and reliable material removal.
