Kyocera S16Q-SVPBR11-22A Internal Turning Toolholder
Couldn't load pickup availability
The Kyocera S16Q-SVPBR11-22A is a precision internal turning and boring bar designed for stable machining of internal diameters on CNC and conventional lathes. Manufactured from high-strength tool steel, this toolholder provides excellent rigidity and vibration resistance for reliable internal turning, profiling, and finishing operations.
Designed to accommodate VBMT size 11 carbide inserts, the toolholder ensures accurate insert positioning and consistent cutting performance. The larger 16 mm shank diameter offers improved rigidity compared to smaller boring bars, making it suitable for deeper internal machining while maintaining stability and surface finish quality.
Key Features & Benefits
- Precision internal boring bar for internal turning applications
- Compatible with VBMT 11 series carbide inserts
- Rigid steel construction for improved machining stability
- Secure insert clamping for reliable cutting performance
- Suitable for internal profiling, finishing, and general boring
- Ideal for CNC lathes and conventional turning machines
Technical Specifications
- Model: S16Q-SVPBR11-22A
- Brand: Kyocera
- Tool Type: Internal Turning Toolholder / Boring Bar
- Insert Size: 11
- Minimum Bore Diameter: 22 mm
- Shank Diameter (DCON): 16 mm
- Head Length (LH): 35 mm
- Total Length (OAL): 180 mm
- Hand: Right-hand
- Material: Steel
- Item No: THC13488
Kyocera cutting tools are trusted worldwide for their precision, durability, and machining efficiency. The S16Q-SVPBR11-22A boring bar provides reliable internal machining performance in production environments, general engineering workshops, and maintenance applications.
