Kyocera WNMG080404PS CA525 – Turning Insert (10 pcs Finishing to Medium, PS Chipbreaker)
The Kyocera WNMG080404PS CA525 is a negative-type trigon turning insert designed for finishing to medium operations on steels. It features the PS chipbreaker, engineered for low cutting resistance, excellent chip evacuation, and smooth cutting action, delivering stable surface quality and dimensional accuracy in continuous and semi-interrupted machining. Manufactured with Kyocera’s CA525 MEGACOAT TOUGH CVD-coated carbide grade, this insert offers an ideal balance of wear resistance, edge strength, and toughness—making it suitable for stable machining under both low and moderate cutting conditions.
Key Features & Benefits
- CA525 Grade – MEGACOAT TOUGH: Advanced CVD-coated carbide optimized for steel turning, combining strong wear resistance with superior toughness.
- PS Chipbreaker: Designed for finishing to medium operations, ensuring smooth chip control and low cutting forces.
- Stable and Reliable: Delivers consistent performance under varying loads, reducing vibration and improving tool life.
- Excellent Surface Finish: Produces high-quality finishes even at higher feed rates.
- Versatile Application: Ideal for carbon and alloy steels in continuous and light-interrupted cutting conditions.
Technical Specifications
- Designation / Order Code: WNMG 080404PS CA525
- Insert Shape: 80° Trigon (W Type)
- Insert Type: Negative Turning Insert
- Material: CVD-Coated Carbide
- Grade: CA525 – MEGACOAT TOUGH (CVD)
- Chipbreaker: PS – Finishing to Medium Geometry
- Inscribed Circle (IC): 12.7 mm
- Thickness (S): 4.76 mm
- Hole Diameter (D1): 5.16 mm
- Corner Radius (RE): 0.4 mm
- Relief Angle: 0° (Negative Type)
- Cutting Depth (ap): 0.1 – 1.2 mm
- Feed Rate (f): 0.05 – 0.35 mm/rev
- Recommended Work Materials: Carbon Steel, Alloy Steel
- Pack Quantity: 10 pcs
About Kyocera CA525:
Kyocera’s CA525 MEGACOAT TOUGH grade combines excellent wear resistance and toughness through advanced CVD coating technology. It ensures reliable performance and extended tool life for a wide range of steel turning applications, particularly in medium-to-finishing operations where precision and consistency are critical.
